Catalogue and technical manual 2022/2023 www.blum.com
① ② ③ Your shortcut to the Internet Catalogue 2022/2023 • KA-150 Example Example Example We have linked our catalogue with our online world, making comprehensive and up-to-date product information available for you to use at any time. You are just one step away from the product page in the catalogue to our E-SERVICES. You can use the web codes to go straight to the respective product in the Product Configurator. This ensures that you will quickly and easily receive planning information and checked parts lists for your direct order from the distributor, as well as so much more. You will find short URLs and QR codes for our products in the catalogue. These will take you directly to our detailed digital information, e.g. the Design Selector, information about assembly, removal and adjustment, application videos and/or the Machinery Directive. The short web address makes it easier for you to access further product information, such as installation instructions that you can print out, brochures and technical data. Directly access information about assembly and indepth content about Blum products via the QR code – even when on-site with the customer. Web code Short URL www.blum.com/configurator Web code DQBQ2M Short URL Help with planning and ordering Short URL www.blum.com/planningtools QR code Application video Short URL www.blum.com/gmSum Enter the web codes into the Blum Product Configurator and you will receive information about the available product range, assembly and marketing along with the parts list. ② Configure fitting Using the web codes, the most important filters are already pre-set in the Product Configurator – you can configure the complete application in just a few clicks. ③ Display the parts list When complete, you receive a finished parts list and can transmit it to the web shop of a selected distributor in just one click. ① Enter or click the web code Enter the web code in the Blum Product Configurator or click the web code in the PDF.
Hinge systems Hinge systems Overview 69 CLIP top BLUMOTION | CLIP top – hinges Tool-free CLIP assembly 70 BLUMOTION for doors 156 TIP-ON for doors 170 MODUL – hinges Slide-on assembly 174 Box systems Box systems Overview 189 TANDEMBOX plus 348 LEGRABOX 190 TIP-ON BLUMOTION for TANDEMBOX 350 TIP-ON BLUMOTION for LEGRABOX 244 SERVO-DRIVE for LEGRABOX | MERIVOBOX | TANDEMBOX 358 TIP-ON for LEGRABOX 250 MERIVOBOX 256 METABOX 390 TIP-ON BLUMOTION for MERIVOBOX 296 TANDEMBOX antaro 302 Runner systems Runner systems Overview 415 MOVENTO 416 TIP-ON BLUMOTION for MOVENTO 434 TIP-ON for MOVENTO 440 TANDEM 446 SERVO-DRIVE for MOVENTO | TANDEM 492 Motion technologies Motion technologies Overview 559 SERVO-DRIVE single applications 562 Further products Further products Overview 573 Cabinet applications SPACE STEP 574 Locking systems CABLOXX 582 Fixing systems EXPANDO T 584 Wall hanging bracket 586 Cabinet connectors 587 E-SERVICES and assembly devices E-SERVICES and assembly devices Overview 591 E-SERVICES 592 Drilling and insertion machines MINIPRESS top | MINIPRESS 604 Assembly devices BOXFIX 644 Templates 650 Inner dividing systems Inner dividing systems Overview 527 AMBIA-LINE for LEGRABOX | MERIVOBOX 528 AMBIA-LINE kitchen accessories 538 ORGA-LINE for TANDEMBOX 540 ORGA-LINE kitchen accessories 554 Information Information Overview 699 General Information 700 Information about lift systems 704 Information about hinge systems 706 Information about box and runner systems 712 Blum’s subsidiaries, representatives and contacts 720 Part No. Index 728 Lift systems Lift systems Overview 15 AVENTOS HF – bi-fold lift system Standard | SERVO-DRIVE 18 AVENTOS HS – up and over lift system Standard | SERVO-DRIVE 30 AVENTOS HL – lift up Standard | SERVO-DRIVE 36 AVENTOS HK top – stay lift Standard | SERVO-DRIVE | TIP-ON 42 AVENTOS HK-S – stay lift Standard | TIP-ON 52 AVENTOS HK-XS – stay lift Standard | TIP-ON 58
1 What we do for you Catalogue 2022/2023 • KA-150 What’s your next project? No matter what your vision is: Blum has you covered. Whether it’s a kitchen, bathroom, living room or bedroom – we have the products to take your projects to the next level. In order to keep this so, we always think a few steps ahead as to which applications you will need in the future and what support will make your job easier. You will find all products and information about our services for your project’s success in our catalogue and technical manual.
2 Catalogue 2022/2023 • KA-150 Ideas from Blum for a higher quality of living No matter if you’re in a house or an apartment, whether it is big or small – we have inspiring cabinet solutions for a variety of different living areas. In addition, we provide you with practical information around ergonomics, storage space maximisation, top quality motion and design. At blum-inspirations.com, you will find everything you need for implementing these furniture ideas, such as appropriate services. We would be happy to tell you more – just get in touch! SPACE STEP This plinth solution enables ergonomic access to high levels in all living areas. REVEGO Pocket systems allow you to quickly open up functional spaces when you need them, and close them off again when they are not in use.
3 Blum Inspirations Catalogue 2022/2023 • KA-150 Design Innovative fittings support your design ideas and enable you to implement the latest furniture trends. SPACE TOWER This spacious larder unit offers convenient access to all storage items. Reference pages Discover more ideas, the right services for implementation and inspiring sales stories Short URL www.blum.com/i362 Ergonomics Wall cabinet fronts equipped with lift systems are better than hinged doors because they lift up and out of the way, providing full freedom of movement. SPACE TWIN This narrow cabinet opens up space for made-tomeasure solutions, even in unexpected places.
4 Catalogue 2022/2023 • KA-150 Turn your inspiration into a reality: myLEGRABOX
5 myLEGRABOX Catalogue 2022/2023 • KA-150 myLEGRABOX 230 LEGRABOX pure/free The basis: LEGRABOX pure and LEGRABOX free offer a selection of superior matt colours and a premium look in anti-fingerprint stainless steel. LEGRABOX special edition The special collection: Incredible drawer side looks based on the new colour, Carbon black matt and stunning material mixes with anti-fingerprint stainless steel, a special 3D Carbon look or a Noble rust textured finish. LEGRABOX individual The ultimate in customisation: design to your heart’s content. Mix colours and materials, use printing, laser texturing and embossing options to add customised designs and create unique furniture that delights your customers. Whatever your inspiration – we have the right design solution to turn the box system into your LEGRABOX. Reference pages Short URL www.blum.com/i357
6 Catalogue 2022/2023 • KA-150 MERIVOBOX Let’s create – the box platform for your ideas
7 MERIVOBOX Catalogue 2022/2023 • KA-150 MERIVOBOX 256 MERIVOBOX modular with gallery Platform It takes just a few components to create your own extensive range. And you can make furniture manufacturing even more efficient at the same time. Diverse and yet simple. Design MERIVOBOX boasts straight lines and a striking look. Create your own diverse and unmistakable range of furniture! Modern minimalism meets distinctive design. Functionality The newly developed cabinet profile concept delivers extremely smooth running action and high load bearing capacity. Coupled with a feather-light glide and enhanced stability. Assembly No matter which model you opt for, assembly is always simple and adjustment always the same. It is extremely easy to achieve precise results. MERIVOBOX modular with BOXCOVER MERIVOBOX modular with BOXCAP Reference pages Short URL www.blum.com/i355
8 Catalogue 2022/2023 • KA-150 Runner systems Quality steel for your design ideas in wood
9 Runner systems Catalogue 2022/2023 • KA-150 Runner systems 414 MOVENTO – the sophisticated runner system Our MOVENTO runner impresses with its stability and high load bearing capacity – now up to 70 kg. That’s why this runner system is ideal for kitchen pull-outs for heavy items such as pots and pans. Reference pages Short URL www.blum.com/i359 TANDEM – the versatile runner system TANDEM is a concealed runner system and the versatile solution for your design in wood. The extremely wide range of options offers great design flexibility. Choose from a broad selection of nominal lengths, various types of extension and load bearing classes as well as optional motion technologies for soft and effortless opening and closing. TANDEM single extension with integrated TIP-ON The TANDEM single extension is available with integrated TIP-ON. This motion technology not only offers your customers greater convenience, but it also saves you time and energy. TIP-ON is integrated in the runner profile so you can provide your customers with an opening support system without any additional work needed for assembly. All you need is a one-piece synchronisation linkage for assembly.
10 Catalogue 2022/2023 • KA-150 Marketing Concept | Planning | Quotation Design Ordering E-SERVICES & assembly devices Good services are there when you need them. As a reliable partner, we offer you services and practical assembly devices that complement our products and support you along every step of your manufacturing process. We will help you transform your ideas into fine furniture. Plan, configure and save your projects effortlessly online. Easily create up-to-date parts lists for your customer quotes. We provide you with our images, videos, brochures and much more in different languages and formats – online in our Marketing Media Library. Our Cabinet and Product Configurators provide you with support when designing cabinets and selecting the right fittings. You receive CAD data that can then be used in your design software. You can transmit the parts lists from our configurators to the web shops of selected distributors via an interface.
11 E-SERVICES and assembly devices Catalogue 2022/2023 • KA-150 Manufacturing Delivery | Assembly After sales service E-SERVICES 592 We provide personal after-sale support. Your contact at Blum will be happy to answer any questions you might have about our products and services. Reference pages Short URL www.blum.com/i361 Digitally transfer your planning results from the configurators to MINIPRESS with EASYSTICK. Using assembly devices such as templates, etc. you can finish your project quickly and precisely. Our EASY ASSEMBLY app contains all you need to know about the assembly and adjustment of fittings, including videos.
12 Catalogue 2022/2023 • KA-150 We believe that ideas can move the world. We offer innovative fittings, inspiring furniture concepts and appropriate services so that you can turn your creative ideas into reality. We are driven by your needs, international trends and our shared vision of a better quality of living. Let us work together to create moving ideas.
13 moving ideas Catalogue 2022/2023 • KA-150 Quality of living We would like you to enjoy greater convenience and functionality when using furniture. Product range Everything from a single source: our wide range of products allows you to keep up with today’s and tomorrow’s trends. Inspiration We monitor global trends and strive to create the solutions of tomorrow. We like to share our insights with you. Innovation We stay in motion. Curiosity and pioneering spirit drive us to develop new products and services for you. Services We support your daily operations with customised services tailored to your processes. Quality We continuously strive to improve our products, services and ourselves. Trust We take responsibility for partnerships, our employees, society and the environment. Julius Blum started our journey in 1952 with horseshoe studs. Today we supply innovative fittings to customers in over 120 countries.
14 Lift systems Catalogue 2022/2023 • KA-150 1 The symmetrical lift mechanism of AVENTOS HK-XS can be used on one or two sides AVENTOS lift systems offer many opportunities for creating cabinets that are even more individual – in all areas of the home SERVO-DRIVE, the electrical motion support system for AVENTOS HF, HS, HL and HK top AVENTOS lift systems deliver enhanced convenience to wall cabinets. Even wide fronts open with ease, hold in any position desired and close softly and effortlessly with soft-close BLUMOTION. TIP-ON, the mechanical opening support system for AVENTOS HK top, HK-S and HK-XS ▬ Quick, easy assembly and removal due to CLIP technology ▬ Easy, 3-dimensional front adjustment ▬ Perfectly balanced – fronts remain in any desired position ▬ No protruding parts ▬ Optimised ergonomic handle position ▬ BLUMOTION – soft and effortless closing action ▬ With SERVO-DRIVE, the electrical motion support system for wall cabinets ▬ With TIP-ON, the mechanical opening support system for stay lifts
15 Lift systems 〉 Overview Catalogue 2022/2023 • KA-150 AVENTOS HF – bi-fold lift system AVENTOS HF – bi-fold lift system 18 Overview 19 Standard | SERVO-DRIVE 20 Accessories 28 AVENTOS HS – up and over lift system AVENTOS HS – up and over lift system 30 Overview 31 Standard | SERVO-DRIVE 32 AVENTOS HL – lift up AVENTOS HL – lift up 36 Overview 37 Standard | SERVO-DRIVE 38 AVENTOS HK top – stay lift AVENTOS HK top – stay lift 42 Overview 43 Standard | SERVO-DRIVE 44 TIP-ON 48 Accessories 51 AVENTOS HK-S – stay lift AVENTOS HK-S – stay lift 52 Overview 53 Standard 54 TIP-ON 54 Accessories 57 AVENTOS HK-XS – stay lift AVENTOS HK-XS – stay lift 58 Overview 59 Standard 60 TIP-ON 60 Accessories 65 AVENTOS – mitred and rebated applications AVENTOS – mitred and rebated applications 16 Accessories Screws 66 Centre bit 66 Door buffer 66 Screwdriver 67 Cross slot bit 67 Lift systems Symbolic image Symbolic image Symbolic image Symbolic image Symbolic image Symbolic image Symbolic image Symbolic image
16 Lift systems 〉 AVENTOS – mitred and rebated applications Catalogue 2022/2023 • KA-150 An inspiring range of lift systems Mitred applications Rebated applications AVENTOS wall cabinet fronts also hold in any position desired when open and are therefore always within easy reach for closing. Extra convenience is provided by the SERVO-DRIVE or TIP-ON opening support systems. Reference pages AVENTOS – mitred and rebated applications Short URL www.blum.com/mitresrebates Lift systems The mesmerising motion of AVENTOS lift systems is also available for wall cabinets with mitres or rebates. Only minor positional adjustments need be made to standard fittings. The new applications allow you to translate creative design ideas into action. Wall cabinets with lift systems are particularly convenient because fronts glide up and out of the user’s way, providing freedom of movement.
17 Lift systems 〉 AVENTOS – mitred and rebated applications Catalogue 2022/2023 • KA-150 Mitred applications Rebated applications AVENTOS HF – bi-fold lift system AVENTOS HS – up and over lift system AVENTOS HL – lift up AVENTOS HK top – stay lift AVENTOS HF – bi-fold lift system AVENTOS HS – up and over lift system AVENTOS HL – lift up AVENTOS HK top – stay lift Lift systems
18 Lift systems 〉 AVENTOS HF – bi-fold lift system Catalogue 2022/2023 • KA-150 Lift system for large bi-fold fronts Other advantages that will inspire both you and your customers Excellent durability The core element of the lift mechanism is a robust spring package. The result: excellent durability No protruding parts Removable telescopic arm – an advantage for furniture manufacturing and kitchen installation Includes a finger safety feature The CLIP top centre hinge with innovative technology ensures finger safety Similar shelves possible Depending on the height of the cabinet, 2 identical shelves can be used The cover cap is available in silk white, light grey and dark grey Enhanced opening and closing ease Thanks to integrated BLUMOTION, both heavy and light fronts close softly and effortlessly The AVENTOS HF has a two-part front that folds together in the centre when opening. The bi-fold lift system is ideal for higher wall cabinets with large fronts because the handle remains easy to reach in any position. AVENTOS HF can also be used with fronts of different heights. ▬ Soft and effortless closing thanks to BLUMOTION ▬ Easy to open ▬ Holds in any position ▬ Provides excellent access to the cabinet interior ▬ Small range, huge application variety ▬ Easy assembly and adjustment ▬ Stability, even with wide fronts ▬ Excellent durability ▬ Free positioning of handles ▬ No protruding parts ▬ Optional: SERVO-DRIVE for AVENTOS, the electrical motion support system for wall cabinets Lift systems Lift systems open effortlessly with AVENTOS HF. Even heavy fronts only require light operating forces. The variable stop ensures that fronts always remain in the desired position
19 Lift systems 〉 AVENTOS HF – bi-fold lift system 〉 Overview Catalogue 2022/2023 • KA-150 Applications Web code Page Standard | SERVO-DRIVE Wooden fronts and wide alu frames DQD8YM 20 Narrow alu frames DQD9NY 24 Accessories Opening angle stop 21 Hinge set 28 Mounting plates 144 Hinge arm cover cap 151 Screws 66 Centre bit 66 Door buffer 66 Screwdriver 67 Cross slot bit 67 Assembly, removal and adjustment Assembly, removal and adjustment Short URL www.blum.com/a110 Machine directive 701 Detailed information on the Machine Directive Short URL www.blum.com/sd/guideline Pictograph Item available on request Lift systems Symbolic image Symbolic image Symbolic image Symbolic image
20 Lift systems 〉 AVENTOS HF – bi-fold lift system 〉 Standard | SERVO-DRIVE Catalogue 2022/2023 • KA-150 Wooden fronts and wide alu frames Web code DQD8YM Power factor LF Cabinet height KH (mm) x combined weight of top and bottom fronts FG including handle (kg) Theoret. cabinet height TKH Upper front height FHo (mm) x 2 + gaps We recommend the more powerful lift mechanism for overlapping areas. Standard SERVO-DRIVE Order information 1 Lift mechanism set Power factor LF Part no. 2600–5500 (1 pc LF 960–2650) 20F2200.05 5350–10150 20F2500.05 9000–17250 (3 pc LF 13500–25900) 20F2800.05 Composed of: 1 2 x Lift mechanism (symmetrical) – 8 x Chipboard screws Ø 4 x 35 mm 2 Telescopic arm set Cabinet height KH (mm) ¹ Part no. 480–570 20F3200.01 560–710 20F3500.01 700–900 20F3800.01 760–1040 20F3900.01 Composed of: 2 2 x Telescopic arm (symmetrical) ¹ Theoretical cabinet height TKH for asymmetrical fronts 3 Cover cap set Colour Material Part no. SW | HGR | TGR Nylon 20F8020 Composed of: 3a 1 x Cover cap left 3b 1 x Cover cap right 3c 2 x Branding element, stamped with Blum logo IN-G 3 Cover cap set for SERVO-DRIVE Colour Material Part no. SW | HGR | TGR Nylon 21F8020 Composed of: 3a 1 x SERVO-DRIVE cover cap left 3b 1 x Cover cap right 3c 2 x Branding element, stamped with Blum logo IN-G 3d 2 x SERVO-DRIVE switch 3e 6 x Blum distance bumper, Ø 5 mm 4 Mounting plate for telescopic arm Recommendation Fixing method Spacing (mm) Part no. Screw-on 0 ¹ 175H3100 EXPANDO 0 177H3100E Knock-in 0 177H3100 All horizontal steel mounting plates with 0 mm spacing possible ¹ Use 2 chipboard screws (609.1x00) per side for wooden fronts ¹ Use 2 counter sunk self tapping screws (660.0950) per side for wide alu frames 6 SERVO-DRIVE set Colour Material Part no. R7037 Nylon 21FA000 Composed of: 6a 1 x Drive unit 6b 1 x SERVO-DRIVE distribution cable, 1500 mm 6c 1 x Connecting node 6d 2 x Cable end protector For three lift mechanisms or more, we recommend two synchronised drive units 7 24 W SERVO-DRIVE power supply unit Language package Part no. Language package Part no. A Z10NE030A F Z10NE030F B Z10NE030B G Z10NE030G C Z10NE030C H Z10NE030H D Z10NE030D J Z10NE030J E Z10NE030E Incl. operating and installation instructions Without flex Language package – operating and installation instructions A DE | EN | FR | IT | NL F BG | ET | LT | LV | RO | RU B DA | EN | FI | NO | SV G EN | ES | FR C EL | EN | HR | SL | SR | TR H EN | ZH D EN | ES | FR | IT | PT J JA E CS | HU | PL | SK Language descriptions as per ISO-639 8 Power supply unit housing Colour Material Part no. WGR Nylon Z10NG120 For 24 W SERVO-DRIVE power supply unit 9 Flex Market Part no. Market Part no. AR Z10M200A JP Z10M200J UK Z10M200B AU Z10M200K CH Z10M200C CL Z10M200L DK Z10M200D CN Z10M200N Europe Z10M200E BR Z10M200S.01 Europe ¹ Z10M200E.OS TW Z10M200T IN Z10M200H US | CA Z10M200U IL Z10M200I ZA Z10M200Z Length 2 m, incl. plug ¹ Without plug Lift systems ▬ Ideal for wall cabinets with bi-fold fronts ▬ Cabinet height KH 480–1040 mm ▬ Cabinet width KB up to 1800 mm ▬ Soft and effortless closing thanks to BLUMOTION ▬ Light operating forces ▬ Variable stop ▬ Tool-free assembly ▬ 3-dimensional adjustment of both fronts ▬ Simple, infinitely variable lift mechanism ▬ Centre hinge with finger safety feature
21 Lift systems 〉 AVENTOS HF – bi-fold lift system 〉 Standard | SERVO-DRIVE Catalogue 2022/2023 • KA-150 Wooden fronts and wide alu frames Web code DQD8YM Order information Alternative to 7 | 8 | 9 – 12 W SERVO-DRIVE plug-in power supply unit Only suitable for one drive unit Network adapter Language package Part no. Network adapter Language package Part no. E A ☎ Z10NA30EAF E F ☎ Z10NA30EFF E B ☎ Z10NA30EBF B A ☎ Z10NA30BAF E C ☎ Z10NA30ECF K D ☎ Z10NA30KDF E D ☎ Z10NA30EDF U G ☎ Z10NA30UGF E E ☎ Z10NA30EEF Network adapter ¹ E B K U Composed of: – 1 x 12 W SERVO-DRIVE plug-in power supply unit Incl. cable, 1120 mm (with SERVO-DRIVE distribution cable extendible to max. 2000 mm) Other combinations available upon request ¹ See the Information chapter for a detailed market list 10 CLIP top 120° hinge Boss Spring Part no. INSERTA Unsprung 70T5590BTL Screw-on Unsprung ² 70T5550.TL Boss overlay TO (fixed dimension) 11 mm 3 hinges at cabinet width KB 1200 mm and/or starting from 12 kg front weight FG 4 hinges at cabinet width KB 1800 mm and/or starting from 20 kg front weight FG ² Use chipboard screws (609.1x00) for wooden fronts ² Use counter sunk self tapping screws (660.0950) for wide alu frames Alternative to 10 10 CLIP top 120° special hinge for larger front overlay Boss Spring Part no. INSERTA Unsprung 72T5590BTL Screw-on Unsprung ² 72T5550.TL Boss overlay TO (fixed dimension) 13 mm 3 hinges at cabinet width KB 1200 mm and/or starting from 12 kg front weight FG 4 hinges at cabinet width KB 1800 mm and/or starting from 20 kg front weight FG ² Use chipboard screws (609.1x00) for wooden fronts ² Use counter sunk self tapping screws (660.0950) for wide alu frames 11 Mounting plate for CLIP top 120° hinge Recommendation Fixing method Spacing (mm) Part no. Screw-on 0 ² 175H3100 EXPANDO 0 177H3100E Knock-in 0 177H3100 Standard mounting plates, spacing depends on the upper front overlay FAo ² Use chipboard screws (609.1x00) for wooden fronts ² Use counter sunk self tapping screws (660.0950) for wide alu frames 12 CLIP top centre hinge Boss Spring Part no. EXPANDO Unsprung 78Z553ET Screw-on Unsprung ² 78Z5500T 3 hinges at cabinet width KB 1200 mm and/or starting from 12 kg front weight FG 4 hinges at cabinet width KB 1800 mm and/or starting from 20 kg front weight FG ² Use chipboard screws (609.1x00) for wooden fronts ² Use counter sunk self tapping screws (660.0950) for wide alu frames 13 Mounting plate for CLIP top-centre hinge Recommendation Fixing method Spacing (mm) Part no. Screw-on 0 ² 175H3100 EXPANDO 0 177H3100E Knock-in 0 177H3100 Standard mounting plates with 0 mm spacing Only use cruciform mounting plates for wide aluminium frames under a 57 mm frame frieze width ² Use chipboard screws (609.1x00) for wooden fronts ² Use counter sunk self tapping screws (660.0950) for wide alu frames Accessories – Opening angle stop Opening angle Colour Part no. 104° TGR 20F7051 83° R7037 20F7011 – SERVO-DRIVE distribution cable and cable end protector Colour Length (m) Part no. S 8 Z10K800AE Composed of: 6b 1 x SERVO-DRIVE distribution cable 6d 5 x Cable end protector For cutting to size Can be used as a SERVO-DRIVE distribution cable – Connecting node and cable end protector Colour Material Part no. S Nylon Z10V100E.01 Composed of: 6c 1 x Connecting node 6d 2 x Cable end protector Tool-free assembly – Cable holder Colour Material Part no. W Nylon Z10K0009 E.g. for fixing the SERVO-DRIVE distribution cable Colour Colour HGR Light grey WGR White grey SW Silk white S Black TGR Dark grey W White R7037 RAL 7037 dust grey IN-G In-mould brushed stainless steel Reference pages Overview – AVENTOS HF 19 Accessories – hinge set 28 Mounting plates 144 Accessories – general 66 Planning – symmetrical 22 Planning – asymmetrical 23 Planning – Blum distance bumper 29 SERVO-DRIVE switch 29 SERVO-DRIVE uno – market list 718 Overview – assembly devices 591 Reference values for front weight FG (kg) 704 Machine directive 701 More technical details 698 Assembly, removal and adjustment Short URL www.blum.com/a110 Lift systems
FHo Y FAo 22 Catalogue 2022/2023 • KA-150 Wooden fronts and wide alu frames Planning Symmetrical Drilling position Space requirement KH Cabinet height Opening angle stop Y (mm) Without FHo x 0.44 + 38 104° FHo x 0.24 + 34 83° 0 FHo Upper front height Front assembly Cabinet height KH (mm) X (mm) 177H3100 | 177H3100E | 177H3100E10 | 177H5100 | 175H3100 | 175H4100 175H5400 | 177H5400E 480–549 70 68 550–1040 47 45 SFA Front overlay of the side panel CLIP top 120° hinge TB Drilling distance F Gap FAo Upper front overlay () CLIP top 120° special hinge CLIP top centre hinge TB Drilling distance F Min. gap 1.5 mm * 37 mm for cruciform mounting plates (37/32) Drilling distance TB MD Front overlay FA (mm) 5 6 7 8 9 10 11 12 13 14 15 16 17 0 3 4 5 6 3 3 4 5 6 6 3 4 5 6 9 3 4 5 6 MD Mounting plate spacing (mm) Drilling distance TB MD Horizontal gap F (mm) between fronts 3 4 5 6 0 6 5 4 3 3 6 9 MD Mounting plate spacing (mm) Screw-on INSERTA | EXPANDO Hinge boss dimensions Web code DQD8YM Cabinet height KH (mm) H (mm) 480–549 KH x 0.3 – 28 550–1040 KH x 0.3 – 57 4 x chipboard screws Ø 4 x 35 mm Drilling for SERVO-DRIVE distribution cable, left only * Drilling depth 5 mm ** Alternative drilling With the CLIP top 120° special hinge, the front overlay FA is always 2 mm larger Lift systems 〉 AVENTOS HF – bi-fold lift system 〉 Standard | SERVO-DRIVE Lift systems
FHo Y FAo 23 Catalogue 2022/2023 • KA-150 Wooden fronts and wide alu frames Web code DQD8YM Planning Asymmetrical Drilling position Theoret. cabinet height TKH (mm) H (mm) 480–549 TKH x 0.3 – 28 550–1040 TKH x 0.3 – 57 4 x chipboard screws Ø 4 x 35 mm Drilling for SERVO-DRIVE distribution cable, left only * Drilling depth 5 mm ** Alternative drilling Space requirement TKH = FHo (mm) x 2 + gaps TKH Theoretical cabinet height FHo Upper front height FHu Lower front height Opening angle stop Y (mm) Without FHo x 0.44 + 38 104° FHo x 0.24 + 34 83° 0 FHo Upper front height The larger front must be at the top! Front assembly Theoret. cabinet height TKH (mm) X (mm) 177H3100 | 177H3100E | 177H3100E10 | 177H5100 | 175H3100 | 175H4100 175H5400 | 177H5400E 480–549 FHo / 2 + 70 FHo / 2 + 68 550–1040 FHo / 2 + 47 FHo / 2 + 45 FHo Upper front height FHu Lower front height FAu Bottom front overlay SFA Front overlay of the side panel CLIP top 120° hinge TB Drilling distance F Gap FAo Upper front overlay () CLIP top 120° special hinge CLIP top centre hinge TB Drilling distance F Min. gap 1.5 mm * 37 mm for cruciform mounting plates (37/32) Drilling distance TB MD Front overlay FA (mm) 5 6 7 8 9 10 11 12 13 14 15 16 17 0 3 4 5 6 3 3 4 5 6 6 3 4 5 6 9 3 4 5 6 MD Mounting plate spacing (mm) With the CLIP top 120° special hinge, the front overlay FA is always 2 mm larger Drilling distance TB MD Horizontal gap F (mm) between fronts 3 4 5 6 0 6 5 4 3 3 6 9 MD Mounting plate spacing (mm) Screw-on INSERTA | EXPANDO Reference pages Overview – AVENTOS HF 19 Ordering information – wooden fronts and wide alu frames 20 Planning – Blum distance bumper 29 SERVO-DRIVE switch 29 Machine directive 701 Assembly, removal and adjustment Short URL www.blum.com/a110 Lift systems 〉 AVENTOS HF – bi-fold lift system 〉 Standard | SERVO-DRIVE Lift systems
24 Catalogue 2022/2023 • KA-150 Narrow alu frames Web code DQD9NY Power factor LF Cabinet height KH (mm) x combined weight of top and bottom fronts FG including handle (kg) Theoret. cabinet height TKH Upper front height FHo (mm) x 2 + gaps We recommend the more powerful lift mechanism for overlapping areas. Standard SERVO-DRIVE Order information Language package – operating and installation instructions A DE | EN | FR | IT | NL F BG | ET | LT | LV | RO | RU B DA | EN | FI | NO | SV G EN | ES | FR C EL | EN | HR | SL | SR | TR H EN | ZH D EN | ES | FR | IT | PT J JA E CS | HU | PL | SK Language descriptions as per ISO-639 ▬ Ideal for wall cabinets with bi-fold fronts ▬ Cabinet height KH 480–1040 mm ▬ Cabinet width KB up to 1800 mm ▬ Soft and effortless closing thanks to BLUMOTION ▬ Light operating forces ▬ Variable stop ▬ Tool-free assembly ▬ 3-dimensional adjustment of both fronts ▬ Simple, infinitely variable lift mechanism ▬ Centre hinge with finger safety feature 1 Lift mechanism set Power factor LF Part no. 2600–5500 (1 pc LF 960–2650) 20F2200.05 5350–10150 20F2500.05 9000–17250 20F2800.05 Composed of: 1 2 x Lift mechanism (symmetrical) – 8 x Chipboard screws Ø 4 x 35 mm 2 Telescopic arm set Cabinet height KH (mm) ¹ Part no. 480–570 20F3200.01 560–710 20F3500.01 700–900 20F3800.01 760–1040 20F3900.01 Composed of: 2 2 x Telescopic arm (symmetrical) ¹ Theoretical cabinet height TKH for asymmetrical fronts 3 Cover cap set Colour Material Part no. SW | HGR | TGR Nylon 20F8020 Composed of: 3a 1 x Cover cap left 3b 1 x Cover cap right 3c 2 x Branding element, stamped with Blum logo IN-G 3 Cover cap set for SERVO-DRIVE Colour Material Part no. SW | HGR | TGR Nylon 21F8020 Composed of: 3a 1 x SERVO-DRIVE cover cap left 3b 1 x Cover cap right 3c 2 x Branding element, stamped with Blum logo IN-G 3d 2 x SERVO-DRIVE switch 3e 6 x Blum distance bumper, Ø 5 mm 4 CLIP adapter plate for telescopic arms Version Spacing (mm) Part no. Left | right 0 175H5B00 6 SERVO-DRIVE set Colour Material Part no. R7037 Nylon 21FA000 Composed of: 6a 1 x Drive unit 6b 1 x SERVO-DRIVE distribution cable, 1500 mm 6c 1 x Connecting node 6d 2 x Cable end protector 7 24 W SERVO-DRIVE power supply unit Language package Part no. Language package Part no. A Z10NE030A F Z10NE030F B Z10NE030B G Z10NE030G C Z10NE030C H Z10NE030H D Z10NE030D J Z10NE030J E Z10NE030E Incl. operating and installation instructions Without flex 8 Power supply unit housing Colour Material Part no. WGR Nylon Z10NG120 For 24 W SERVO-DRIVE power supply unit 9 Flex Market Part no. Market Part no. AR Z10M200A JP Z10M200J UK Z10M200B AU Z10M200K CH Z10M200C CL Z10M200L DK Z10M200D CN Z10M200N Europe Z10M200E BR Z10M200S.01 Europe ¹ Z10M200E.OS TW Z10M200T IN Z10M200H US | CA Z10M200U IL Z10M200I ZA Z10M200Z Length 2 m, incl. plug ¹ Without plug Lift systems 〉 AVENTOS HF – bi-fold lift system 〉 Standard | SERVO-DRIVE Lift systems
25 Lift systems 〉 AVENTOS HF – bi-fold lift system 〉 Standard | SERVO-DRIVE Catalogue 2022/2023 • KA-150 Narrow alu frames Web code DQD9NY Order information Alternative to 7 | 8 | 9 – 12 W SERVO-DRIVE plug-in power supply unit Only suitable for one drive unit Network adapter Language package Part no. Network adapter Language package Part no. E A ☎ Z10NA30EAF E F ☎ Z10NA30EFF E B ☎ Z10NA30EBF B A ☎ Z10NA30BAF E C ☎ Z10NA30ECF K D ☎ Z10NA30KDF E D ☎ Z10NA30EDF U G ☎ Z10NA30UGF E E ☎ Z10NA30EEF Network adapter ¹ E B K U Composed of: – 1 x 12 W SERVO-DRIVE plug-in power supply unit Incl. cable, 1120 mm (with SERVO-DRIVE distribution cable extendible to max. 2000 mm) Other combinations available upon request ¹ See the Information chapter for a detailed market list 10 CLIP top 120° aluminium frame door hinge Boss Spring Part no. Screw-on Unsprung 72T550A.TL 3 hinges at cabinet width KB 1200 mm and/or starting from 12 kg front weight FG 4 hinges at cabinet width KB 1800 mm and/or starting from 20 kg front weight FG Boss fixing screws are included 11 Mounting plate for CLIP top 120° hinge Recommendation Fixing method Spacing (mm) Part no. Screw-on 0 ² 175H3100 EXPANDO 0 177H3100E Knock-in 0 177H3100 Standard mounting plates, spacing depends on the top gap F ² Use 2 counter sunk self tapping screws (660.0950) per side for narrow alu frames 12 CLIP top aluminium centre hinge Boss Spring Part no. Screw-on Unsprung 78Z550AT 3 hinges at cabinet width KB 1200 mm and/or starting from 12 kg front weight FG 4 hinges at cabinet width KB 1800 mm and/or starting from 20 kg front weight FG Use 2 counter sunk self tapping screws (660.0950) per side for narrow alu frames 13 CLIP adapter plate for centre hinges Version Spacing (mm) Part no. Symmetrical 0 175H5A00 Boss fixing screws are included Accessories – Opening angle stop Opening angle Colour Part no. 104° TGR 20F7051 83° R7037 20F7011 – SERVO-DRIVE distribution cable and cable end protector Colour Length (m) Part no. S 8 Z10K800AE Composed of: 6b 1 x SERVO-DRIVE distribution cable 6d 5 x Cable end protector For cutting to size Can be used as a SERVO-DRIVE distribution cable – Connecting node and cable end protector Colour Material Part no. S Nylon Z10V100E.01 Composed of: 6c 1 x Connecting node 6d 2 x Cable end protector Tool-free assembly – Cable holder Colour Material Part no. W Nylon Z10K0009 E.g. for fixing the SERVO-DRIVE distribution cable Colour Colour HGR Light grey WGR White grey SW Silk white S Black TGR Dark grey W White R7037 RAL 7037 dust grey IN-G In-mould brushed stainless steel Reference pages Overview – AVENTOS HF 19 Accessories – hinge set 28 Mounting plates 144 Accessories – general 66 Planning – symmetrical 26 Planning – asymmetrical 27 Planning – Blum distance bumper 29 SERVO-DRIVE switch 29 SERVO-DRIVE uno – market list 718 Overview – assembly devices 591 Reference values for front weight FG (kg) 704 Machine directive 701 More technical details 698 Assembly, removal and adjustment Short URL www.blum.com/a110 Lift systems
FHo Y 26 Catalogue 2022/2023 • KA-150 Narrow alu frames Planning Symmetrical Drilling position Space requirement KH Cabinet height Opening angle stop Y (mm) Without FHo x 0.44 + 38 104° FHo x 0.24 + 34 83° 0 FHo Upper front height Front assembly Cabinet height KH (mm) X (mm) 480–549 54 550–1040 31 CLIP top 120° aluminium frame door hinge CLIP top aluminium centre hinge F Min. gap 1.5 mm The gap F needs to be adjusted for frame thicknesses over 20.5 mm Screw-on (hinge | adapter plate) * When changing material thickness, adjust the assembly dimensions accordingly Web code DQD9NY Cabinet height KH (mm) H (mm) 480–549 KH x 0.3 – 28 550–1040 KH x 0.3 – 57 4 x chipboard screws Ø 4 x 35 mm Drilling for SERVO-DRIVE distribution cable, left only * Drilling depth 5 mm ** Alternative drilling Lift systems 〉 AVENTOS HF – bi-fold lift system 〉 Standard | SERVO-DRIVE Lift systems
FHo Y 27 Catalogue 2022/2023 • KA-150 Narrow alu frames Web code DQD9NY Planning Asymmetrical Drilling position Theoret. cabinet height TKH (mm) H (mm) 480–549 TKH x 0.3 – 28 550–1040 TKH x 0.3 – 57 4 x chipboard screws Ø 4 x 35 mm Drilling for SERVO-DRIVE distribution cable, left only * Drilling depth 5 mm ** Alternative drilling Space requirement TKH = FHo (mm) x 2 + gaps TKH Theoretical cabinet height FHo Upper front height FHu Lower front height Opening angle stop Y (mm) Without FHo x 0.44 + 38 104° FHo x 0.24 + 34 83° 0 FHo Upper front height The larger front must be at the top! Front assembly Theoret. cabinet height TKH (mm) X (mm) 480–549 FHo / 2 + 54 550–1040 FHo / 2 + 31 FHo Upper front height FHu Lower front height FAu Bottom front overlay CLIP top 120° aluminium frame door hinge CLIP top aluminium centre hinge F Min. gap 1.5 mm The gap F needs to be adjusted for frame thicknesses over 20.5 mm Screw-on (hinge | adapter plate) * When changing material thickness, adjust the assembly dimensions accordingly Reference pages Overview – AVENTOS HF 19 Ordering information – narrow alu frames 24 Planning – Blum distance bumper 29 SERVO-DRIVE switch 29 Machine directive 701 Assembly, removal and adjustment Short URL www.blum.com/a110 Lift systems 〉 AVENTOS HF – bi-fold lift system 〉 Standard | SERVO-DRIVE Lift systems
28 Lift systems 〉 AVENTOS HF – bi-fold lift system 〉 Accessories Catalogue 2022/2023 • KA-150 Hinge set – wooden fronts Order information Fixing method Part no. INSERTA | Knock-in | EXPANDO ☎ 78Z5530T11 Composed of: 2 x CLIP top 120° hinge unsprung 70T5590BTL 2 x CLIP top centre hinge unsprung 78Z5530T 6 x Horizontal cam mounting plate 177H3100 Hinge set – wooden fronts and wide aluminium frames Order information Fixing method Part no. Screw-on ¹ ☎ 78Z5500T12 Composed of: 2 x CLIP top 120° hinge unsprung 70T5550.TL 2 x CLIP top centre hinge unsprung 78Z5500T 6 x Horizontal cam mounting plate 175H3100 For wide alu frames, an additional cruciform mounting plate is required for the CLIP top centre hinge ¹ Use chipboard screws (609.1x00) for wooden fronts ¹ Use counter sunk self tapping screws (660.0950) for wide alu frames Hinge set – narrow aluminium frames Order information Fixing method Part no. Screw-on ☎ 78Z550AT11 Composed of: 2 x CLIP top 120° aluminium frame hinge unsprung 72T550A.TL 2 x CLIP top alu centre hinge unsprung 78Z550AT 2 x Horizontal cam mounting plate 175H5400 2 x CLIP adapter plate symmetrical 175H5A00 2 x CLIP adapter plate left/right 175H5B00 Lift systems ▬ Hinge set ▬ Hinge set ▬ Hinge set
29 Lift systems 〉 AVENTOS HF – bi-fold lift system 〉 Planning Catalogue 2022/2023 • KA-150 Planning Blum distance bumper (SERVO-DRIVE application only) Insert Blum distance bumper (do not glue) Recommendation for aluminium frames A trial application must be carried out when fixing to the front * From cabinet bottom edge for fronts that protrude below SERVO-DRIVE switch Overview – AVENTOS HF 19 Ordering information – wooden fronts and wide alu frames 20 Ordering information – narrow alu frames 24 Overview – assembly devices 591 Machine directive 701 More technical details 698 Take into account drilling for the Blum distance bumper in the cabinet side Reference pages Assembly, removal and adjustment Short URL www.blum.com/a110 Lift systems
30 Lift systems 〉 AVENTOS HS – up and over lift system Catalogue 2022/2023 • KA-150 Ease of use and design options Other advantages that will inspire both you and your customers Excellent durability The core element of the lift mechanism is a robust spring package. The result: excellent durability No protruding parts Removable lever arm – an advantage for furniture manufacturing and kitchen installation AVENTOS HS provides ease of use that inspires. Even heavy fronts are easy to open thanks to the light operating forces Thanks to SERVO-DRIVE, wall cabinet fronts open at a single touch. The press of a switch is all you need for a soft close The cover cap is available in silk white, light grey and dark grey Cornice and crown moulding You can easily combine cabinets with cornice or crown moulding with AVENTOS HS. This provides more design freedom for furniture planning The up and over lift system for a smooth glide AVENTOS HS can be used with EXPANDO T for thin fronts measuring 8 mm or more Lift systems Wall cabinet fronts equipped with AVENTOS HS swing up and over the cabinet, making it ideal for large fronts. The up and over lift system is also the perfect choice for cabinets with cornices. ▬ Soft and effortless closing thanks to BLUMOTION ▬ Easy to open ▬ Holds in any position ▬ Provides excellent access to the cabinet interior ▬ Suitable for wall cabinets with cornice or crown moulding ▬ Small range, huge application variety ▬ Easy assembly and adjustment ▬ Stability, even with wide fronts ▬ Excellent durability ▬ No protruding parts ▬ Optional: SERVO-DRIVE for AVENTOS, the electrical motion support system for wall cabinets
31 Lift systems 〉 AVENTOS HS – up and over lift system 〉 Overview Catalogue 2022/2023 • KA-150 Applications Web code Page Standard | SERVO-DRIVE Wooden fronts, wide and narrow alu frames DQDADA 32 Accessories Screws 66 Centre bit 66 Door buffer 66 Screwdriver 67 Cross slot bit 67 Assembly, removal and adjustment Assembly, removal and adjustment Short URL www.blum.com/a120 Machine directive 701 Detailed information on the Machine Directive Short URL www.blum.com/sd/guideline Pictograph Item available on request Lift systems Symbolic image Symbolic image Symbolic image
32 Lift systems 〉 AVENTOS HS – up and over lift system 〉 Standard | SERVO-DRIVE Catalogue 2022/2023 • KA-150 Wooden fronts, wide and narrow alu frames Web code DQDADA Lift mechanism In order to select the correct lift mechanism, it is necessary to determine both the cabinet height KH and the front weight FG (including the handle) Example Cabinet height KH = 600 mm Front weight FG = 10 kg Lift mechanism selection = 20S2E00.05 KH = 602 mm –> 600 mm KH = 603 mm –> 605 mm We recommend the more powerful lift mechanism for overlapping areas. Standard SERVO-DRIVE Order information 1 Lift mechanism set Cabinet height KH 350–525 mm Part no. 20S2A00.05 20S2B00.05 20S2C00.05 Part no. 20S2A00.05 20S2B00.05 20S2C00.05 KH (mm) Weight of front incl. handle (kg) KH (mm) Weight of front incl. handle (kg) 350 2.00–5.00 4.50–9.50 9.25–10.50 440 2.25–4.50 4.25–8.50 8.25–13.00 355 2.00–4.75 4.50–9.50 9.25–10.50 445 2.25–4.50 4.25–8.50 8.25–13.25 360 2.00–4.75 4.50–9.50 9.25–10.75 450 2.25–4.25 4.00–8.50 8.25–13.50 365 2.00–4.75 4.50–9.25 9.00–11.00 455 2.25–4.25 4.00–8.50 8.25–13.50 370 2.00–4.75 4.50–9.25 9.00–11.00 460 2.25–4.25 4.00–8.25 8.00–13.75 375 2.00–4.75 4.50–9.25 9.00–11.25 465 2.25–4.25 4.00–8.25 8.00–13.75 380 2.00–4.75 4.50–9.25 9.00–11.25 470 2.50–4.25 4.00–8.25 8.00–14.00 385 2.00–4.75 4.50–9.25 9.00–11.50 475 2.50–4.25 3.75–8.00 7.75–14.00 390 2.00–4.75 4.50–9.00 8.75–11.50 480 2.50–4.25 3.75–8.00 7.75–14.25 395 2.00–4.75 4.50–9.00 8.75–11.75 485 2.50–4.25 3.75–8.00 7.75–14.25 400 2.00–4.75 4.25–9.00 8.75–12.00 490 2.50–4.25 3.75–8.00 7.75–14.50 405 2.25–4.50 4.25–9.00 8.75–12.00 495 2.50–4.25 3.75–7.75 7.50–14.50 410 2.25–4.50 4.25–9.00 8.75–12.25 500 2.50–4.25 3.50–7.75 7.50–14.75 415 2.25–4.50 4.25–8.75 8.50–12.50 505 2.50–4.00 3.50–7.75 7.50–14.75 420 2.25–4.50 4.25–8.75 8.50–12.50 510 2.50–4.00 3.50–7.75 7.50–14.75 425 2.25–4.50 4.25–8.75 8.50–12.75 515 2.50–4.00 3.50–7.50 7.25–14.75 430 2.25–4.50 4.25–8.75 8.50–12.75 520 2.50–4.00 3.50–7.50 7.25–15.00 435 2.25–4.50 4.25–8.75 8.50–13.00 525 2.50–4.00 3.25–7.50 7.25–15.00 Cabinet height KH 526–675 mm Part no. 20S2D00.05 20S2E00.05 20S2F00.05 Part no. 20S2D00.05 20S2E00.05 20S2F00.05 KH (mm) Weight of front incl. handle (kg) KH (mm) Weight of front incl. handle (kg) 526 3.00–6.75 6.25–13.00 12.00–16.50 605 3.00–6.00 5.50–11.75 10.50–18.50 530 3.00–6.75 6.25–12.75 11.75–16.75 610 3.00–6.00 5.50–11.75 10.50–18.50 535 3.00–6.75 6.25–12.75 11.75–16.75 615 3.00–5.75 5.50–11.50 10.25–18.75 540 3.00–6.50 6.00–12.75 11.75–17.00 620 3.00–5.75 5.50–11.50 10.25–18.75 545 3.00–6.50 6.00–12.50 11.50–17.25 625 3.00–5.75 5.50–11.50 10.25–18.75 550 3.00–6.50 6.00–12.50 11.50–17.25 630 3.00–5.75 5.50–11.50 10.25–18.75 555 3.00–6.50 6.00–12.50 11.50–17.50 635 3.00–5.50 5.25–11.50 10.25–18.75 560 3.00–6.50 6.00–12.25 11.25–17.50 640 3.00–5.50 5.25–11.25 10.00–18.75 565 3.00–6.25 5.75–12.25 11.25–17.75 645 3.00–5.50 5.25–11.25 10.00–18.75 570 3.00–6.25 5.75–12.25 11.25–17.75 650 3.00–5.50 5.25–11.25 10.00–19.00 575 3.00–6.25 5.75–12.00 11.00–18.00 655 3.00–5.50 5.25–11.25 10.00–19.00 580 3.00–6.25 5.75–12.00 11.00–18.00 660 3.00–5.50 5.25–11.25 10.00–19.00 585 3.00–6.25 5.75–12.00 10.75–18.25 665 3.00–5.25 5.00–11.00 09.75–19.00 590 3.00–6.00 5.50–12.00 10.75–18.25 670 3.00–5.25 5.00–11.00 09.75–19.00 595 3.00–6.00 5.50–11.75 10.50–18.50 675 3.00–5.25 5.00–11.00 09.75–19.00 600 3.00–6.00 5.50–11.75 10.50–18.50 Cabinet height KH 676–800 mm Part no. 20S2G00.05 20S2H00.05 20S2I00.05 Part no. 20S2G00.05 20S2H00.05 20S2I00.05 KH (mm) Weight of front incl. handle (kg) KH (mm) Weight of front incl. handle (kg) 676 3.50–8.00 7.00–13.50 13.00–21.50 740 3.50–7.25 6.50–12.75 11.75–20.75 680 3.50–8.00 7.00–13.50 13.00–21.50 745 3.50–7.25 6.50–12.75 11.50–20.50 685 3.50–8.00 7.00–13.25 12.75–21.50 750 3.50–7.25 6.50–12.75 11.50–20.50 690 3.50–7.75 6.75–13.25 12.75–21.50 755 3.75–7.25 6.50–12.75 11.25–20.50 695 3.50–7.75 6.75–13.25 12.50–21.50 760 3.75–7.25 6.50–12.75 11.25–20.25 700 3.50–7.75 6.75–13.25 12.50–21.50 765 3.75–7.25 6.50–12.50 11.00–20.25 705 3.50–7.75 6.75–13.25 12.25–21.50 770 3.75–7.00 6.25–12.50 11.00–20.25 710 3.50–7.75 6.75–13.25 12.25–21.25 775 3.75–7.00 6.25–12.50 11.00–20.25 715 3.50–7.50 6.75–13.00 12.00–21.25 780 4.00–7.00 6.25–12.50 10.75–20.25 720 3.50–7.50 6.75–13.00 12.00–21.25 785 4.00–7.00 6.25–12.50 10.75–20.00 725 3.50–7.50 6.75–13.00 12.00–21.00 790 4.00–7.00 6.00–12.25 10.75–20.00 730 3.50–7.50 6.75–13.00 11.75–21.00 795 4.00–7.00 6.00–12.25 10.50–20.00 735 3.50–7.50 6.50–13.00 11.75–20.75 800 4.00–7.00 6.00–12.25 10.50–20.00 Composed of: 1 2 x Lift mechanism (symmetrical) – 10 x Chipboard screws Ø 4 x 35 mm KH Cabinet height 2 Lever arm set Colour Material Part no. NI Steel 20S3500.06 Composed of: 2a 1 x Lever arm left 2b 1 x Lever arm right 2c 2 x Cross stabiliser cover cap 2 Lever arm set for SERVO-DRIVE Colour Material Part no. NI Steel 21S3500.01 Composed of: 2a 1 x SERVO-DRIVE lever arm left 2b 1 x SERVO-DRIVE lever arm right 2c 2 x Cross stabiliser cover cap 3 Cover cap set Colour Material Part no. SW | HGR | TGR Nylon 20S8020 Composed of: 3a 1 x Cover cap left 3b 1 x Cover cap right 3c 2 x Branding element, stamped with Blum logo IN-G 3 Cover cap set for SERVO-DRIVE Colour Material Part no. SW | HGR | TGR Nylon 21S8020 Composed of: 3a 1 x SERVO-DRIVE cover cap left 3b 1 x Cover cap right 3c 2 x Branding element, stamped with Blum logo IN-G 3d 2 x SERVO-DRIVE switch 3e 4 x Blum distance bumper, Ø 5 mm Lift systems ▬ Ideal for large fronts ▬ Cabinet height KH 350–800 mm ▬ Cabinet width KB up to 1800 mm ▬ Soft and effortless closing thanks to BLUMOTION ▬ Light operating forces ▬ Perfect motion with a variable stop ▬ Tool-free assembly ▬ 3-dimensional front adjustment ▬ Simple, infinitely variable lift mechanism
33 Catalogue 2022/2023 • KA-150 Wooden fronts, wide and narrow alu frames Order information Language package – operating and installation instructions A DE | EN | FR | IT | NL F BG | ET | LT | LV | RO | RU B DA | EN | FI | NO | SV G EN | ES | FR C EL | EN | HR | SL | SR | TR H EN | ZH D EN | ES | FR | IT | PT J JA E CS | HU | PL | SK Language descriptions as per ISO-639 Composed of: – 1 x 12 W SERVO-DRIVE plug-in power supply unit Incl. cable, 1120 mm (with SERVO-DRIVE distribution cable extendible to max. 2000 mm) Other combinations available upon request ¹ See the Information chapter for a detailed market list Accessories Colour Colour HGR Light grey R7037 RAL 7037 dust grey SW Silk white WGR White grey TGR Dark grey S Black NI Nickel plated W White IN-G In-mould brushed stainless steel Overview – AVENTOS HS 31 Fixing system for thin fronts – EXPANDO T 584 Assembly recommendation and limitation of liability – EXPANDO T 585 Accessories – general 66 Planning 34 Planning – Blum distance bumper 35 SERVO-DRIVE switch 35 SERVO-DRIVE uno – market list 718 Overview – assembly devices 591 Reference values for front weight FG (kg) 704 Machine directive 701 More technical details 698 Web code DQDADA Reference pages Assembly, removal and adjustment Short URL www.blum.com/a120 4 Front fixing bracket set Version Part no. Wooden fronts and wide alu frames ¹ 20S4200 Narrow alu frames 20S4200A ¹ Use 4 chipboard screws (609.1x00) per side for wooden fronts ¹ Use 4 counter sunk self tapping screws (660.0950) per side for wide alu frames 4 Front fixing bracket Version Part no. Thin fronts 20S42T1 EXPANDO T suitable for thin fronts – see reference pages 5 Cross stabiliser rod round Length (mm) Diameter (mm) Part no. 1061 Ø 16 20Q1061UN For cutting to size Cutting Internal cabinet width LW – 129 mm Internal cabinet width LW – 164 mm – Connecting piece set for cross stabiliser Internal cabinet width LW 1190 mm and higher Material Diameter (mm) Part no. Aluminium Ø 16 20Q153ZN Composed of: – 1 x Connecting piece – 1 x Fixing – 2 x Cross stabiliser cover cap Cutting for 5 Internal cabinet width LW / 2 – 147 mm Internal cabinet width LW / 2 – 165 mm 6 SERVO-DRIVE set Colour Material Part no. R7037 Nylon 21FA000 Composed of: 6a 1 x Drive unit 6b 1 x SERVO-DRIVE distribution cable, 1500 mm 6c 1 x Connecting node 6d 2 x Cable end protector We recommend one SERVO-DRIVE drive unit per set for connected fronts 7 24 W SERVO-DRIVE power supply unit Language package Part no. Language package Part no. A Z10NE030A F Z10NE030F B Z10NE030B G Z10NE030G C Z10NE030C H Z10NE030H D Z10NE030D J Z10NE030J E Z10NE030E Incl. operating and installation instructions Without flex 8 Power supply unit housing Colour Material Part no. WGR Nylon Z10NG120 For 24 W SERVO-DRIVE power supply unit 9 Flex Market Part no. Market Part no. AR Z10M200A JP Z10M200J UK Z10M200B AU Z10M200K CH Z10M200C CL Z10M200L DK Z10M200D CN Z10M200N Europe Z10M200E BR Z10M200S.01 Europe ¹ Z10M200E.OS TW Z10M200T IN Z10M200H US | CA Z10M200U IL Z10M200I ZA Z10M200Z Length 2 m, incl. plug ¹ Without plug Alternative to 7 | 8 | 9 – 12 W SERVO-DRIVE plug-in power supply unit Only suitable for one drive unit Network adapter Language package Part no. Network adapter Language package Part no. E A ☎ Z10NA30EAF E F ☎ Z10NA30EFF E B ☎ Z10NA30EBF B A ☎ Z10NA30BAF E C ☎ Z10NA30ECF K D ☎ Z10NA30KDF E D ☎ Z10NA30EDF U G ☎ Z10NA30UGF E E ☎ Z10NA30EEF Network adapter ¹ E B K U – SERVO-DRIVE distribution cable and cable end protector Colour Length (m) Part no. S 8 Z10K800AE Composed of: 6b 1 x SERVO-DRIVE distribution cable 6d 5 x Cable end protector For cutting to size Can be used as a SERVO-DRIVE distribution cable – Connecting node and cable end protector Colour Material Part no. S Nylon Z10V100E.01 Composed of: 6c 1 x Connecting node 6d 2 x Cable end protector Tool-free assembly – Cable holder Colour Material Part no. W Nylon Z10K0009 E.g. for fixing the SERVO-DRIVE distribution cable Lift systems 〉 AVENTOS HS – up and over lift system 〉 Standard | SERVO-DRIVE Lift systems
